深入浅出LevelDB —— 07 Cache

// Copyright (c) 2011 The LevelDB Authors. All rights reserved.
// Use of this source code is governed by a BSD-style license that can be
// found in the LICENSE file. See the AUTHORS file for names of contributors.
//
// A Cache is an interface that maps keys to values.  It has internal
// synchronization and may be safely accessed concurrently from
// multiple threads.  It may automatically evict entries to make room
// for new entries.  Values have a specified charge against the cache
// capacity.  For example, a cache where the values are variable
// length strings, may use the length of the string as the charge for
// the string.
//
// A builtin cache implementation with a least-recently-used eviction
// policy is provided.  Clients may use their own implementations if
// they want something more sophisticated (like scan-resistance, a
// custom eviction policy, variable cache sizing, etc.)

#ifndef STORAGE_LEVELDB_INCLUDE_CACHE_H_
#define STORAGE_LEVELDB_INCLUDE_CACHE_H_

#include <cstdint>

#include "leveldb/export.h"
#include "leveldb/slice.h"

namespace leveldb {

class LEVELDB_EXPORT Cache;

// Create a new cache with a fixed size capacity.  This implementation
// of Cache uses a least-recently-used eviction policy.
LEVELDB_EXPORT Cache* NewLRUCache(size_t capacity);

class LEVELDB_EXPORT Cache {
 public:
  Cache() = default;

  Cache(const Cache&) = delete;
  Cache& operator=(const Cache&) = delete;

  // Destroys all existing entries by calling the "deleter"
  // function that was passed to the constructor.
  virtual ~Cache();

  // Opaque handle to an entry stored in the cache.
  struct Handle {};

  // Insert a mapping from key->value into the cache and assign it
  // the specified charge against the total cache capacity.
  //
  // Returns a handle that corresponds to the mapping.  The caller
  // must call this->Release(handle) when the returned mapping is no
  // longer needed.
  //
  // When the inserted entry is no longer needed, the key and
  // value will be passed to "deleter".
  virtual Handle* Insert(const Slice& key, void* value, size_t charge,
                         void (*deleter)(const Slice& key, void* value)) = 0;

  // If the cache has no mapping for "key", returns nullptr.
  //
  // Else return a handle that corresponds to the mapping.  The caller
  // must call this->Release(handle) when the returned mapping is no
  // longer needed.
  virtual Handle* Lookup(const Slice& key) = 0;

  // Release a mapping returned by a previous Lookup().
  // REQUIRES: handle must not have been released yet.
  // REQUIRES: handle must have been returned by a method on *this.
  virtual void Release(Handle* handle) = 0;

  // Return the value encapsulated in a handle returned by a
  // successful Lookup().
  // REQUIRES: handle must not have been released yet.
  // REQUIRES: handle must have been returned by a method on *this.
  virtual void* Value(Handle* handle) = 0;

  // If the cache contains entry for key, erase it.  Note that the
  // underlying entry will be kept around until all existing handles
  // to it have been released.
  virtual void Erase(const Slice& key) = 0;

  // Return a new numeric id.  May be used by multiple clients who are
  // sharing the same cache to partition the key space.  Typically the
  // client will allocate a new id at startup and prepend the id to
  // its cache keys.
  virtual uint64_t NewId() = 0;

  // Remove all cache entries that are not actively in use.  Memory-constrained
  // applications may wish to call this method to reduce memory usage.
  // Default implementation of Prune() does nothing.  Subclasses are strongly
  // encouraged to override the default implementation.  A future release of
  // leveldb may change Prune() to a pure abstract method.
  virtual void Prune() {}

  // Return an estimate of the combined charges of all elements stored in the
  // cache.
  virtual size_t TotalCharge() const = 0;

 private:
  void LRU_Remove(Handle* e);
  void LRU_Append(Handle* e);
  void Unref(Handle* e);

  struct Rep;
  Rep* rep_;
};

}  // namespace leveldb

#endif  // STORAGE_LEVELDB_INCLUDE_CACHE_H_

  Cache() = default;

  Cache(const Cache&) = delete;
  Cache& operator=(const Cache&) = delete;

  // Destroys all existing entries by calling the "deleter"
  // function that was passed to the constructor.
  virtual ~Cache();

  // Opaque handle to an entry stored in the cache.
  struct Handle {};

  // Insert a mapping from key->value into the cache and assign it
  // the specified charge against the total cache capacity.
  //
  // Returns a handle that corresponds to the mapping.  The caller
  // must call this->Release(handle) when the returned mapping is no
  // longer needed.
  //
  // When the inserted entry is no longer needed, the key and
  // value will be passed to "deleter".
  virtual Handle* Insert(const Slice& key, void* value, size_t charge,
                         void (*deleter)(const Slice& key, void* value)) = 0;

  // If the cache has no mapping for "key", returns nullptr.
  //
  // Else return a handle that corresponds to the mapping.  The caller
  // must call this->Release(handle) when the returned mapping is no
  // longer needed.
  virtual Handle* Lookup(const Slice& key) = 0;

  // Release a mapping returned by a previous Lookup().
  // REQUIRES: handle must not have been released yet.
  // REQUIRES: handle must have been returned by a method on *this.
  virtual void Release(Handle* handle) = 0;

// LRU cache implementation
//
// Cache entries have an "in_cache" boolean indicating whether the cache has a
// reference on the entry.  The only ways that this can become false without the
// entry being passed to its "deleter" are via Erase(), via Insert() when
// an element with a duplicate key is inserted, or on destruction of the cache.
//
// The cache keeps two linked lists of items in the cache.  All items in the
// cache are in one list or the other, and never both.  Items still referenced
// by clients but erased from the cache are in neither list.  The lists are:
// - in-use:  contains the items currently referenced by clients, in no
//   particular order.  (This list is used for invariant checking.  If we
//   removed the check, elements that would otherwise be on this list could be
//   left as disconnected singleton lists.)
// - LRU:  contains the items not currently referenced by clients, in LRU order
// Elements are moved between these lists by the Ref() and Unref() methods,
// when they detect an element in the cache acquiring or losing its only
// external reference.

// An entry is a variable length heap-allocated structure.  Entries
// are kept in a circular doubly linked list ordered by access time.
struct LRUHandle {
  void* value;
  void (*deleter)(const Slice&, void* value);
  LRUHandle* next_hash;
  LRUHandle* next;
  LRUHandle* prev;
  size_t charge;  // TODO(opt): Only allow uint32_t?
  size_t key_length;
  bool in_cache;     // Whether entry is in the cache.
  uint32_t refs;     // References, including cache reference, if present.
  uint32_t hash;     // Hash of key(); used for fast sharding and comparisons
  char key_data[1];  // Beginning of key

  Slice key() const {
    // next_ is only equal to this if the LRU handle is the list head of an
    // empty list. List heads never have meaningful keys.
    assert(next != this);

    return Slice(key_data, key_length);
  }
};

 private:
  // The table consists of an array of buckets where each bucket is
  // a linked list of cache entries that hash into the bucket.
  uint32_t length_;
  uint32_t elems_;
  LRUHandle** list_;

  // Return a pointer to slot that points to a cache entry that
  // matches key/hash.  If there is no such cache entry, return a
  // pointer to the trailing slot in the corresponding linked list.
  LRUHandle** FindPointer(const Slice& key, uint32_t hash) {
    LRUHandle** ptr = &list_[hash & (length_ - 1)];
    while (*ptr != nullptr && ((*ptr)->hash != hash || key != (*ptr)->key())) {
      ptr = &(*ptr)->next_hash;
    }
    return ptr;
  }

  void Resize() {
    uint32_t new_length = 4;
    while (new_length < elems_) {
      new_length *= 2;
    }
    LRUHandle** new_list = new LRUHandle*[new_length];
    memset(new_list, 0, sizeof(new_list[0]) * new_length);
    uint32_t count = 0;
    for (uint32_t i = 0; i < length_; i++) {
      LRUHandle* h = list_[i];
      while (h != nullptr) {
        LRUHandle* next = h->next_hash;
        uint32_t hash = h->hash;
        LRUHandle** ptr = &new_list[hash & (new_length - 1)];
        h->next_hash = *ptr;
        *ptr = h;
        h = next;
        count++;
      }
    }
    assert(elems_ == count);
    delete[] list_;
    list_ = new_list;
    length_ = new_length;
  }

  LRUHandle* Lookup(const Slice& key, uint32_t hash) {
    return *FindPointer(key, hash);
  }

  LRUHandle* Insert(LRUHandle* h) {
    LRUHandle** ptr = FindPointer(h->key(), h->hash);
    LRUHandle* old = *ptr;
    h->next_hash = (old == nullptr ? nullptr : old->next_hash);
    *ptr = h;
    if (old == nullptr) {
      ++elems_;
      if (elems_ > length_) {
        // Since each cache entry is fairly large, we aim for a small
        // average linked list length (<= 1).
        Resize();
      }
    }
    return old;
  }

  LRUHandle* Remove(const Slice& key, uint32_t hash) {
    LRUHandle** ptr = FindPointer(key, hash);
    LRUHandle* result = *ptr;
    if (result != nullptr) {
      *ptr = result->next_hash;
      --elems_;
    }
    return result;
  }

class LRUCache {

// ... ...

 private:

  // ... ...

  // Initialized before use.
  size_t capacity_;

  // mutex_ protects the following state.
  mutable port::Mutex mutex_;
  size_t usage_ GUARDED_BY(mutex_);

  // Dummy head of LRU list.
  // lru.prev is newest entry, lru.next is oldest entry.
  // Entries have refs==1 and in_cache==true.
  LRUHandle lru_ GUARDED_BY(mutex_);

  // Dummy head of in-use list.
  // Entries are in use by clients, and have refs >= 2 and in_cache==true.
  LRUHandle in_use_ GUARDED_BY(mutex_);

  HandleTable table_ GUARDED_BY(mutex_);
};

void LRUCache::Ref(LRUHandle* e) {
  if (e->refs == 1 && e->in_cache) {  // If on lru_ list, move to in_use_ list.
    LRU_Remove(e);
    LRU_Append(&in_use_, e);
  }
  e->refs++;
}

void LRUCache::Unref(LRUHandle* e) {
  assert(e->refs > 0);
  e->refs--;
  if (e->refs == 0) {  // Deallocate.
    assert(!e->in_cache);
    (*e->deleter)(e->key(), e->value);
    free(e);
  } else if (e->in_cache && e->refs == 1) {
    // No longer in use; move to lru_ list.
    LRU_Remove(e);
    LRU_Append(&lru_, e);
  }
}

void LRUCache::LRU_Remove(LRUHandle* e) {
  e->next->prev = e->prev;
  e->prev->next = e->next;
}

void LRUCache::LRU_Append(LRUHandle* list, LRUHandle* e) {
  // Make "e" newest entry by inserting just before *list
  e->next = list;
  e->prev = list->prev;
  e->prev->next = e;
  e->next->prev = e;
}

class ShardedLRUCache : public Cache {
 private:
  LRUCache shard_[kNumShards];
  port::Mutex id_mutex_;
  uint64_t last_id_;

  static inline uint32_t HashSlice(const Slice& s) {
    return Hash(s.data(), s.size(), 0);
  }

  static uint32_t Shard(uint32_t hash) { return hash >> (32 - kNumShardBits); }

  // ... ...

}

class TableCache {
 public:
  TableCache(const std::string& dbname, const Options& options, int entries);
  ~TableCache();

  // Return an iterator for the specified file number (the corresponding
  // file length must be exactly "file_size" bytes).  If "tableptr" is
  // non-null, also sets "*tableptr" to point to the Table object
  // underlying the returned iterator, or to nullptr if no Table object
  // underlies the returned iterator.  The returned "*tableptr" object is owned
  // by the cache and should not be deleted, and is valid for as long as the
  // returned iterator is live.
  Iterator* NewIterator(const ReadOptions& options, uint64_t file_number,
                        uint64_t file_size, Table** tableptr = nullptr);

  // If a seek to internal key "k" in specified file finds an entry,
  // call (*handle_result)(arg, found_key, found_value).
  Status Get(const ReadOptions& options, uint64_t file_number,
             uint64_t file_size, const Slice& k, void* arg,
             void (*handle_result)(void*, const Slice&, const Slice&));

  // Evict any entry for the specified file number
  void Evict(uint64_t file_number);

 private:
  Status FindTable(uint64_t file_number, uint64_t file_size, Cache::Handle**);

  Env* const env_;
  const std::string dbname_;
  const Options& options_;
  Cache* cache_;
};

}  // namespace leveldb

struct TableAndFile {
  RandomAccessFile* file;
  Table* table;
};

Status TableCache::FindTable(uint64_t file_number, uint64_t file_size,
                             Cache::Handle** handle) {
  Status s;
  char buf[sizeof(file_number)];
  EncodeFixed64(buf, file_number);
  Slice key(buf, sizeof(buf));
  *handle = cache_->Lookup(key);
  if (*handle == nullptr) {
    std::string fname = TableFileName(dbname_, file_number);
    RandomAccessFile* file = nullptr;
    Table* table = nullptr;
    s = env_->NewRandomAccessFile(fname, &file);
    if (!s.ok()) {
      std::string old_fname = SSTTableFileName(dbname_, file_number);
      if (env_->NewRandomAccessFile(old_fname, &file).ok()) {
        s = Status::OK();
      }
    }
    if (s.ok()) {
      s = Table::Open(options_, file, file_size, &table);
    }

    if (!s.ok()) {
      assert(table == nullptr);
      delete file;
      // We do not cache error results so that if the error is transient,
      // or somebody repairs the file, we recover automatically.
    } else {
      TableAndFile* tf = new TableAndFile;
      tf->file = file;
      tf->table = table;
      *handle = cache_->Insert(key, tf, 1, &DeleteEntry);
    }
  }
  return s;
}

Status TableCache::Get(const ReadOptions& options, uint64_t file_number,
                       uint64_t file_size, const Slice& k, void* arg,
                       void (*handle_result)(void*, const Slice&,
                                             const Slice&)) {
  Cache::Handle* handle = nullptr;
  Status s = FindTable(file_number, file_size, &handle);
  if (s.ok()) {
    Table* t = reinterpret_cast<TableAndFile*>(cache_->Value(handle))->table;
    s = t->InternalGet(options, k, arg, handle_result);
    cache_->Release(handle);
  }
  return s;
}

// A Table is a sorted map from strings to strings.  Tables are
// immutable and persistent.  A Table may be safely accessed from
// multiple threads without external synchronization.
class LEVELDB_EXPORT Table {
 public:
  // Attempt to open the table that is stored in bytes [0..file_size)
  // of "file", and read the metadata entries necessary to allow
  // retrieving data from the table.
  //
  // If successful, returns ok and sets "*table" to the newly opened
  // table.  The client should delete "*table" when no longer needed.
  // If there was an error while initializing the table, sets "*table"
  // to nullptr and returns a non-ok status.  Does not take ownership of
  // "*source", but the client must ensure that "source" remains live
  // for the duration of the returned table's lifetime.
  //
  // *file must remain live while this Table is in use.
  static Status Open(const Options& options, RandomAccessFile* file,
                     uint64_t file_size, Table** table);

  Table(const Table&) = delete;
  Table& operator=(const Table&) = delete;

  ~Table();

  // Returns a new iterator over the table contents.
  // The result of NewIterator() is initially invalid (caller must
  // call one of the Seek methods on the iterator before using it).
  Iterator* NewIterator(const ReadOptions&) const;

  // Given a key, return an approximate byte offset in the file where
  // the data for that key begins (or would begin if the key were
  // present in the file).  The returned value is in terms of file
  // bytes, and so includes effects like compression of the underlying data.
  // E.g., the approximate offset of the last key in the table will
  // be close to the file length.
  uint64_t ApproximateOffsetOf(const Slice& key) const;

 private:
  friend class TableCache;
  struct Rep;

  static Iterator* BlockReader(void*, const ReadOptions&, const Slice&);

  explicit Table(Rep* rep) : rep_(rep) {}

  // Calls (*handle_result)(arg, ...) with the entry found after a call
  // to Seek(key).  May not make such a call if filter policy says
  // that key is not present.
  Status InternalGet(const ReadOptions&, const Slice& key, void* arg,
                     void (*handle_result)(void* arg, const Slice& k,
                                           const Slice& v));

  void ReadMeta(const Footer& footer);
  void ReadFilter(const Slice& filter_handle_value);

  Rep* const rep_;
};

struct Table::Rep {
  ~Rep() {
    delete filter;
    delete[] filter_data;
    delete index_block;
  }

  Options options;
  Status status;
  RandomAccessFile* file;
  uint64_t cache_id;
  FilterBlockReader* filter;
  const char* filter_data;

  BlockHandle metaindex_handle;  // Handle to metaindex_block: saved from footer
  Block* index_block;
};

Status Table::Open(const Options& options, RandomAccessFile* file,
                   uint64_t size, Table** table) {
  *table = nullptr;
  if (size < Footer::kEncodedLength) {
    return Status::Corruption("file is too short to be an sstable");
  }

  char footer_space[Footer::kEncodedLength];
  Slice footer_input;
  Status s = file->Read(size - Footer::kEncodedLength, Footer::kEncodedLength,
                        &footer_input, footer_space);
  if (!s.ok()) return s;

  Footer footer;
  s = footer.DecodeFrom(&footer_input);
  if (!s.ok()) return s;

  // Read the index block
  BlockContents index_block_contents;
  ReadOptions opt;
  if (options.paranoid_checks) {
    opt.verify_checksums = true;
  }
  s = ReadBlock(file, opt, footer.index_handle(), &index_block_contents);

  if (s.ok()) {
    // We've successfully read the footer and the index block: we're
    // ready to serve requests.
    Block* index_block = new Block(index_block_contents);
    Rep* rep = new Table::Rep;
    rep->options = options;
    rep->file = file;
    rep->metaindex_handle = footer.metaindex_handle();
    rep->index_block = index_block;
    rep->cache_id = (options.block_cache ? options.block_cache->NewId() : 0);
    rep->filter_data = nullptr;
    rep->filter = nullptr;
    *table = new Table(rep);
    (*table)->ReadMeta(footer);
  }

  return s;
}

// Convert an index iterator value (i.e., an encoded BlockHandle)
// into an iterator over the contents of the corresponding block.
Iterator* Table::BlockReader(void* arg, const ReadOptions& options,
                             const Slice& index_value) {
  Table* table = reinterpret_cast<Table*>(arg);
  Cache* block_cache = table->rep_->options.block_cache;
  Block* block = nullptr;
  Cache::Handle* cache_handle = nullptr;

  BlockHandle handle;
  Slice input = index_value;
  Status s = handle.DecodeFrom(&input);
  // We intentionally allow extra stuff in index_value so that we
  // can add more features in the future.

  if (s.ok()) {
    BlockContents contents;
    if (block_cache != nullptr) {
      char cache_key_buffer[16];
      EncodeFixed64(cache_key_buffer, table->rep_->cache_id);
      EncodeFixed64(cache_key_buffer + 8, handle.offset());
      Slice key(cache_key_buffer, sizeof(cache_key_buffer));
      cache_handle = block_cache->Lookup(key);
      if (cache_handle != nullptr) {
        block = reinterpret_cast<Block*>(block_cache->Value(cache_handle));
      } else {
        s = ReadBlock(table->rep_->file, options, handle, &contents);
        if (s.ok()) {
          block = new Block(contents);
          if (contents.cachable && options.fill_cache) {
            cache_handle = block_cache->Insert(key, block, block->size(),
                                               &DeleteCachedBlock);
          }
        }
      }
    } else {
      s = ReadBlock(table->rep_->file, options, handle, &contents);
      if (s.ok()) {
        block = new Block(contents);
      }
    }
  }

  Iterator* iter;
  if (block != nullptr) {
    iter = block->NewIterator(table->rep_->options.comparator);
    if (cache_handle == nullptr) {
      iter->RegisterCleanup(&DeleteBlock, block, nullptr);
    } else {
      iter->RegisterCleanup(&ReleaseBlock, block_cache, cache_handle);
    }
  } else {
    iter = NewErrorIterator(s);
  }
  return iter;
}

Status Table::InternalGet(const ReadOptions& options, const Slice& k, void* arg,
                          void (*handle_result)(void*, const Slice&,
                                                const Slice&)) {
  Status s;
  Iterator* iiter = rep_->index_block->NewIterator(rep_->options.comparator);
  iiter->Seek(k);
  if (iiter->Valid()) {
    Slice handle_value = iiter->value();
    FilterBlockReader* filter = rep_->filter;
    BlockHandle handle;
    if (filter != nullptr && handle.DecodeFrom(&handle_value).ok() &&
        !filter->KeyMayMatch(handle.offset(), k)) {
      // Not found
    } else {
      Iterator* block_iter = BlockReader(this, options, iiter->value());
      block_iter->Seek(k);
      if (block_iter->Valid()) {
        (*handle_result)(arg, block_iter->key(), block_iter->value());
      }
      s = block_iter->status();
      delete block_iter;
    }
  }
  if (s.ok()) {
    s = iiter->status();
  }
  delete iiter;
  return s;
}
