深入浅出etcd/raft —— 0x05 Raft成员变更

// MajorityConfig is a set of IDs that uses majority quorums to make decisions.
type MajorityConfig map[uint64]struct{}

// quorum.go

// AckedIndexer allows looking up a commit index for a given ID of a voter
// from a corresponding MajorityConfig.
type AckedIndexer interface {
	AckedIndex(voterID uint64) (idx Index, found bool)
}

// tracker.go

type matchAckIndexer map[uint64]*Progress

// AckedIndex implements IndexLookuper.
func (l matchAckIndexer) AckedIndex(id uint64) (quorum.Index, bool) {
	pr, ok := l[id]
	if !ok {
		return 0, false
	}
	return quorum.Index(pr.Match), true
}

// JointConfig is a configuration of two groups of (possibly overlapping)
// majority configurations. Decisions require the support of both majorities.
type JointConfig [2]MajorityConfig

// VoteResult takes a mapping of voters to yes/no (true/false) votes and returns
// a result indicating whether the vote is pending, lost, or won. A joint quorum
// requires both majority quorums to vote in favor.
func (c JointConfig) VoteResult(votes map[uint64]bool) VoteResult {
	r1 := c[0].VoteResult(votes)
	r2 := c[1].VoteResult(votes)

	if r1 == r2 {
		// If they agree, return the agreed state.
		return r1
	}
	if r1 == VoteLost || r2 == VoteLost {
		// If either config has lost, loss is the only possible outcome.
		return VoteLost
	}
	// One side won, the other one is pending, so the whole outcome is.
	return VotePending
}

// Config reflects the configuration tracked in a ProgressTracker.
type Config struct {
	Voters quorum.JointConfig
	// AutoLeave is true if the configuration is joint and a transition to the
	// incoming configuration should be carried out automatically by Raft when
	// this is possible. If false, the configuration will be joint until the
	// application initiates the transition manually.
	AutoLeave bool
	// Learners is a set of IDs corresponding to the learners active in the
	// current configuration.
	//
	// Invariant: Learners and Voters does not intersect, i.e. if a peer is in
	// either half of the joint config, it can't be a learner; if it is a
	// learner it can't be in either half of the joint config. This invariant
	// simplifies the implementation since it allows peers to have clarity about
	// its current role without taking into account joint consensus.
	Learners map[uint64]struct{}
	// When we turn a voter into a learner during a joint consensus transition,
	// we cannot add the learner directly when entering the joint state. This is
	// because this would violate the invariant that the intersection of
	// voters and learners is empty. For example, assume a Voter is removed and
	// immediately re-added as a learner (or in other words, it is demoted):
	//
	// Initially, the configuration will be
	//
	//   voters:   {1 2 3}
	//   learners: {}
	//
	// and we want to demote 3. Entering the joint configuration, we naively get
	//
	//   voters:   {1 2} & {1 2 3}
	//   learners: {3}
	//
	// but this violates the invariant (3 is both voter and learner). Instead,
	// we get
	//
	//   voters:   {1 2} & {1 2 3}
	//   learners: {}
	//   next_learners: {3}
	//
	// Where 3 is now still purely a voter, but we are remembering the intention
	// to make it a learner upon transitioning into the final configuration:
	//
	//   voters:   {1 2}
	//   learners: {3}
	//   next_learners: {}
	//
	// Note that next_learners is not used while adding a learner that is not
	// also a voter in the joint config. In this case, the learner is added
	// right away when entering the joint configuration, so that it is caught up
	// as soon as possible.
	LearnersNext map[uint64]struct{}
}

// ProgressTracker tracks the currently active configuration and the information
// known about the nodes and learners in it. In particular, it tracks the match
// index for each peer which in turn allows reasoning about the committed index.
type ProgressTracker struct {
	Config

	Progress ProgressMap

	Votes map[uint64]bool

	MaxInflight int
}

		// stepLeader
		// case pb.MsgProp:
		// ... ...

		for i := range m.Entries {
			e := &m.Entries[i]
			var cc pb.ConfChangeI
			if e.Type == pb.EntryConfChange {
				var ccc pb.ConfChange
				if err := ccc.Unmarshal(e.Data); err != nil {
					panic(err)
				}
				cc = ccc
			} else if e.Type == pb.EntryConfChangeV2 {
				var ccc pb.ConfChangeV2
				if err := ccc.Unmarshal(e.Data); err != nil {
					panic(err)
				}
				cc = ccc
			}
			if cc != nil {
				alreadyPending := r.pendingConfIndex > r.raftLog.applied
				alreadyJoint := len(r.prs.Config.Voters[1]) > 0
				wantsLeaveJoint := len(cc.AsV2().Changes) == 0

				var refused string
				if alreadyPending {
					refused = fmt.Sprintf("possible unapplied conf change at index %d (applied to %d)", r.pendingConfIndex, r.raftLog.applied)
				} else if alreadyJoint && !wantsLeaveJoint {
					refused = "must transition out of joint config first"
				} else if !alreadyJoint && wantsLeaveJoint {
					refused = "not in joint state; refusing empty conf change"
				}

				if refused != "" {
					r.logger.Infof("%x ignoring conf change %v at config %s: %s", r.id, cc, r.prs.Config, refused)
					m.Entries[i] = pb.Entry{Type: pb.EntryNormal}
				} else {
					r.pendingConfIndex = r.raftLog.lastIndex() + uint64(i) + 1
				}
			}
		}

		// ... ...

func (r *raft) applyConfChange(cc pb.ConfChangeV2) pb.ConfState {
	cfg, prs, err := func() (tracker.Config, tracker.ProgressMap, error) {
		changer := confchange.Changer{
			Tracker:   r.prs,
			LastIndex: r.raftLog.lastIndex(),
		}
		if cc.LeaveJoint() {
			return changer.LeaveJoint()
		} else if autoLeave, ok := cc.EnterJoint(); ok {
			return changer.EnterJoint(autoLeave, cc.Changes...)
		}
		return changer.Simple(cc.Changes...)
	}()

	if err != nil {
		// TODO(tbg): return the error to the caller.
		panic(err)
	}

	return r.switchToConfig(cfg, prs)
}

// switchToConfig reconfigures this node to use the provided configuration. It
// updates the in-memory state and, when necessary, carries out additional
// actions such as reacting to the removal of nodes or changed quorum
// requirements.
//
// The inputs usually result from restoring a ConfState or applying a ConfChange.
func (r *raft) switchToConfig(cfg tracker.Config, prs tracker.ProgressMap) pb.ConfState {
	r.prs.Config = cfg
	r.prs.Progress = prs

	r.logger.Infof("%x switched to configuration %s", r.id, r.prs.Config)
	cs := r.prs.ConfState()
	pr, ok := r.prs.Progress[r.id]

	// Update whether the node itself is a learner, resetting to false when the
	// node is removed.
	r.isLearner = ok && pr.IsLearner

	if (!ok || r.isLearner) && r.state == StateLeader {
		// This node is leader and was removed or demoted. We prevent demotions
		// at the time writing but hypothetically we handle them the same way as
		// removing the leader: stepping down into the next Term.
		//
		// TODO(tbg): step down (for sanity) and ask follower with largest Match
		// to TimeoutNow (to avoid interruption). This might still drop some
		// proposals but it's better than nothing.
		//
		// TODO(tbg): test this branch. It is untested at the time of writing.
		return cs
	}

	// The remaining steps only make sense if this node is the leader and there
	// are other nodes.
	if r.state != StateLeader || len(cs.Voters) == 0 {
		return cs
	}

	if r.maybeCommit() {
		// If the configuration change means that more entries are committed now,
		// broadcast/append to everyone in the updated config.
		r.bcastAppend()
	} else {
		// Otherwise, still probe the newly added replicas; there's no reason to
		// let them wait out a heartbeat interval (or the next incoming
		// proposal).
		r.prs.Visit(func(id uint64, pr *tracker.Progress) {
			r.maybeSendAppend(id, false /* sendIfEmpty */)
		})
	}
	// If the the leadTransferee was removed or demoted, abort the leadership transfer.
	if _, tOK := r.prs.Config.Voters.IDs()[r.leadTransferee]; !tOK && r.leadTransferee != 0 {
		r.abortLeaderTransfer()
	}

	return cs
}

		if r.prs.Config.AutoLeave && oldApplied <= r.pendingConfIndex && newApplied >= r.pendingConfIndex && r.state == StateLeader {
			// If the current (and most recent, at least for this leader's term)
			// configuration should be auto-left, initiate that now. We use a
			// nil Data which unmarshals into an empty ConfChangeV2 and has the
			// benefit that appendEntry can never refuse it based on its size
			// (which registers as zero).
			ent := pb.Entry{
				Type: pb.EntryConfChangeV2,
				Data: nil,
			}
			// There's no way in which this proposal should be able to be rejected.
			if !r.appendEntry(ent) {
				panic("refused un-refusable auto-leaving ConfChangeV2")
			}
			r.pendingConfIndex = r.raftLog.lastIndex()
			r.logger.Infof("initiating automatic transition out of joint configuration %s", r.prs.Config)
		}
