深入浅出etcd/raft —— 0x04 Raft日志

// Storage is an interface that may be implemented by the application
// to retrieve log entries from storage.
//
// If any Storage method returns an error, the raft instance will
// become inoperable and refuse to participate in elections; the
// application is responsible for cleanup and recovery in this case.
type Storage interface {
	// TODO(tbg): split this into two interfaces, LogStorage and StateStorage.

	// InitialState returns the saved HardState and ConfState information.
	InitialState() (pb.HardState, pb.ConfState, error)
	// Entries returns a slice of log entries in the range [lo,hi).
	// MaxSize limits the total size of the log entries returned, but
	// Entries returns at least one entry if any.
	Entries(lo, hi, maxSize uint64) ([]pb.Entry, error)
	// Term returns the term of entry i, which must be in the range
	// [FirstIndex()-1, LastIndex()]. The term of the entry before
	// FirstIndex is retained for matching purposes even though the
	// rest of that entry may not be available.
	Term(i uint64) (uint64, error)
	// LastIndex returns the index of the last entry in the log.
	LastIndex() (uint64, error)
	// FirstIndex returns the index of the first log entry that is
	// possibly available via Entries (older entries have been incorporated
	// into the latest Snapshot; if storage only contains the dummy entry the
	// first log entry is not available).
	FirstIndex() (uint64, error)
	// Snapshot returns the most recent snapshot.
	// If snapshot is temporarily unavailable, it should return ErrSnapshotTemporarilyUnavailable,
	// so raft state machine could know that Storage needs some time to prepare
	// snapshot and call Snapshot later.
	Snapshot() (pb.Snapshot, error)
}

// MemoryStorage implements the Storage interface backed by an
// in-memory array.
type MemoryStorage struct {
	// Protects access to all fields. Most methods of MemoryStorage are
	// run on the raft goroutine, but Append() is run on an application
	// goroutine.
	sync.Mutex

	hardState pb.HardState
	snapshot  pb.Snapshot
	// ents[i] has raft log position i+snapshot.Metadata.Index
	ents []pb.Entry
}

// unstable.entries[i] has raft log position i+unstable.offset.
// Note that unstable.offset may be less than the highest log
// position in storage; this means that the next write to storage
// might need to truncate the log before persisting unstable.entries.
type unstable struct {
	// the incoming unstable snapshot, if any.
	snapshot *pb.Snapshot
	// all entries that have not yet been written to storage.
	entries []pb.Entry
	offset  uint64

	logger Logger
}

// maybeFirstIndex returns the index of the first possible entry in entries
// if it has a snapshot.
func (u *unstable) maybeFirstIndex() (uint64, bool) {
	if u.snapshot != nil {
		return u.snapshot.Metadata.Index + 1, true
	}
	return 0, false
}

// maybeLastIndex returns the last index if it has at least one
// unstable entry or snapshot.
func (u *unstable) maybeLastIndex() (uint64, bool) {
	if l := len(u.entries); l != 0 {
		return u.offset + uint64(l) - 1, true
	}
	if u.snapshot != nil {
		return u.snapshot.Metadata.Index, true
	}
	return 0, false
}

func (u *unstable) truncateAndAppend(ents []pb.Entry) {
	after := ents[0].Index
	switch {
	case after == u.offset+uint64(len(u.entries)):
		// after is the next index in the u.entries
		// directly append
		u.entries = append(u.entries, ents...)
	case after <= u.offset:
		u.logger.Infof("replace the unstable entries from index %d", after)
		// The log is being truncated to before our current offset
		// portion, so set the offset and replace the entries
		u.offset = after
		u.entries = ents
	default:
		// truncate to after and copy to u.entries
		// then append
		u.logger.Infof("truncate the unstable entries before index %d", after)
		u.entries = append([]pb.Entry{}, u.slice(u.offset, after)...)
		u.entries = append(u.entries, ents...)
	}
}

// shrinkEntriesArray discards the underlying array used by the entries slice
// if most of it isn't being used. This avoids holding references to a bunch of
// potentially large entries that aren't needed anymore. Simply clearing the
// entries wouldn't be safe because clients might still be using them.
func (u *unstable) shrinkEntriesArray() {
	// We replace the array if we're using less than half of the space in
	// it. This number is fairly arbitrary, chosen as an attempt to balance
	// memory usage vs number of allocations. It could probably be improved
	// with some focused tuning.
	const lenMultiple = 2
	if len(u.entries) == 0 {
		u.entries = nil
	} else if len(u.entries)*lenMultiple < cap(u.entries) {
		newEntries := make([]pb.Entry, len(u.entries))
		copy(newEntries, u.entries)
		u.entries = newEntries
	}
}

type raftLog struct {
	// storage contains all stable entries since the last snapshot.
	storage Storage

	// unstable contains all unstable entries and snapshot.
	// they will be saved into storage.
	unstable unstable

	// committed is the highest log position that is known to be in
	// stable storage on a quorum of nodes.
	committed uint64
	// applied is the highest log position that the application has
	// been instructed to apply to its state machine.
	// Invariant: applied <= committed
	applied uint64

	logger Logger

	// maxNextEntsSize is the maximum number aggregate byte size of the messages
	// returned from calls to nextEnts.
	maxNextEntsSize uint64
}

func (l *raftLog) firstIndex() uint64 {
	if i, ok := l.unstable.maybeFirstIndex(); ok {
		return i
	}
	index, err := l.storage.FirstIndex()
	if err != nil {
		panic(err) // TODO(bdarnell)
	}
	return index
}

func (l *raftLog) lastIndex() uint64 {
	if i, ok := l.unstable.maybeLastIndex(); ok {
		return i
	}
	i, err := l.storage.LastIndex()
	if err != nil {
		panic(err) // TODO(bdarnell)
	}
	return i
}

// newLog returns log using the given storage and default options. It
// recovers the log to the state that it just commits and applies the
// latest snapshot.
func newLog(storage Storage, logger Logger) *raftLog {
	return newLogWithSize(storage, logger, noLimit)
}

// newLogWithSize returns a log using the given storage and max
// message size.
func newLogWithSize(storage Storage, logger Logger, maxNextEntsSize uint64) *raftLog {
	if storage == nil {
		log.Panic("storage must not be nil")
	}
	log := &raftLog{
		storage:         storage,
		logger:          logger,
		maxNextEntsSize: maxNextEntsSize,
	}
	firstIndex, err := storage.FirstIndex()
	if err != nil {
		panic(err) // TODO(bdarnell)
	}
	lastIndex, err := storage.LastIndex()
	if err != nil {
		panic(err) // TODO(bdarnell)
	}
	log.unstable.offset = lastIndex + 1
	log.unstable.logger = logger
	// Initialize our committed and applied pointers to the time of the last compaction.
	log.committed = firstIndex - 1
	log.applied = firstIndex - 1

	return log
}

// maybeAppend returns (0, false) if the entries cannot be appended. Otherwise,
// it returns (last index of new entries, true).
func (l *raftLog) maybeAppend(index, logTerm, committed uint64, ents ...pb.Entry) (lastnewi uint64, ok bool) {
	if l.matchTerm(index, logTerm) {
		lastnewi = index + uint64(len(ents))
		ci := l.findConflict(ents)
		switch {
		case ci == 0:
		case ci <= l.committed:
			l.logger.Panicf("entry %d conflict with committed entry [committed(%d)]", ci, l.committed)
		default:
			offset := index + 1
			l.append(ents[ci-offset:]...)
		}
		l.commitTo(min(committed, lastnewi))
		return lastnewi, true
	}
	return 0, false
}

func (l *raftLog) append(ents ...pb.Entry) uint64 {
	if len(ents) == 0 {
		return l.lastIndex()
	}
	if after := ents[0].Index - 1; after < l.committed {
		l.logger.Panicf("after(%d) is out of range [committed(%d)]", after, l.committed)
	}
	l.unstable.truncateAndAppend(ents)
	return l.lastIndex()
}

// findConflict finds the index of the conflict.
// It returns the first pair of conflicting entries between the existing
// entries and the given entries, if there are any.
// If there is no conflicting entries, and the existing entries contains
// all the given entries, zero will be returned.
// If there is no conflicting entries, but the given entries contains new
// entries, the index of the first new entry will be returned.
// An entry is considered to be conflicting if it has the same index but
// a different term.
// The first entry MUST have an index equal to the argument 'from'.
// The index of the given entries MUST be continuously increasing.
func (l *raftLog) findConflict(ents []pb.Entry) uint64 {
	for _, ne := range ents {
		if !l.matchTerm(ne.Index, ne.Term) {
			if ne.Index <= l.lastIndex() {
				l.logger.Infof("found conflict at index %d [existing term: %d, conflicting term: %d]",
					ne.Index, l.zeroTermOnErrCompacted(l.term(ne.Index)), ne.Term)
			}
			return ne.Index
		}
	}
	return 0
}

// slice returns a slice of log entries from lo through hi-1, inclusive.
func (l *raftLog) slice(lo, hi, maxSize uint64) ([]pb.Entry, error) {
	err := l.mustCheckOutOfBounds(lo, hi)
	if err != nil {
		return nil, err
	}
	if lo == hi {
		return nil, nil
	}
	var ents []pb.Entry
	if lo < l.unstable.offset {
		storedEnts, err := l.storage.Entries(lo, min(hi, l.unstable.offset), maxSize)
		if err == ErrCompacted {
			return nil, err
		} else if err == ErrUnavailable {
			l.logger.Panicf("entries[%d:%d) is unavailable from storage", lo, min(hi, l.unstable.offset))
		} else if err != nil {
			panic(err) // TODO(bdarnell)
		}

		// check if ents has reached the size limitation
		if uint64(len(storedEnts)) < min(hi, l.unstable.offset)-lo {
			return storedEnts, nil
		}

		ents = storedEnts
	}
	if hi > l.unstable.offset {
		unstable := l.unstable.slice(max(lo, l.unstable.offset), hi)
		if len(ents) > 0 {
			combined := make([]pb.Entry, len(ents)+len(unstable))
			n := copy(combined, ents)
			copy(combined[n:], unstable)
			ents = combined
		} else {
			ents = unstable
		}
	}
	return limitSize(ents, maxSize), nil
}

// l.firstIndex <= lo <= hi <= l.firstIndex + len(l.entries)
func (l *raftLog) mustCheckOutOfBounds(lo, hi uint64) error {
	if lo > hi {
		l.logger.Panicf("invalid slice %d > %d", lo, hi)
	}
	fi := l.firstIndex()
	if lo < fi {
		return ErrCompacted
	}

	length := l.lastIndex() + 1 - fi
	if hi > fi+length {
		l.logger.Panicf("slice[%d,%d) out of bound [%d,%d]", lo, hi, fi, l.lastIndex())
	}
	return nil
}

// Progress represents a follower’s progress in the view of the leader. Leader
// maintains progresses of all followers, and sends entries to the follower
// based on its progress.
//
// NB(tbg): Progress is basically a state machine whose transitions are mostly
// strewn around `*raft.raft`. Additionally, some fields are only used when in a
// certain State. All of this isn't ideal.
type Progress struct {
	Match, Next uint64
	// State defines how the leader should interact with the follower.
	//
	// When in StateProbe, leader sends at most one replication message
	// per heartbeat interval. It also probes actual progress of the follower.
	//
	// When in StateReplicate, leader optimistically increases next
	// to the latest entry sent after sending replication message. This is
	// an optimized state for fast replicating log entries to the follower.
	//
	// When in StateSnapshot, leader should have sent out snapshot
	// before and stops sending any replication message.
	State StateType

	// PendingSnapshot is used in StateSnapshot.
	// If there is a pending snapshot, the pendingSnapshot will be set to the
	// index of the snapshot. If pendingSnapshot is set, the replication process of
	// this Progress will be paused. raft will not resend snapshot until the pending one
	// is reported to be failed.
	PendingSnapshot uint64

	// RecentActive is true if the progress is recently active. Receiving any messages
	// from the corresponding follower indicates the progress is active.
	// RecentActive can be reset to false after an election timeout.
	//
	// TODO(tbg): the leader should always have this set to true.
	RecentActive bool

	// ProbeSent is used while this follower is in StateProbe. When ProbeSent is
	// true, raft should pause sending replication message to this peer until
	// ProbeSent is reset. See ProbeAcked() and IsPaused().
	ProbeSent bool

	// Inflights is a sliding window for the inflight messages.
	// Each inflight message contains one or more log entries.
	// The max number of entries per message is defined in raft config as MaxSizePerMsg.
	// Thus inflight effectively limits both the number of inflight messages
	// and the bandwidth each Progress can use.
	// When inflights is Full, no more message should be sent.
	// When a leader sends out a message, the index of the last
	// entry should be added to inflights. The index MUST be added
	// into inflights in order.
	// When a leader receives a reply, the previous inflights should
	// be freed by calling inflights.FreeLE with the index of the last
	// received entry.
	Inflights *Inflights

	// IsLearner is true if this progress is tracked for a learner.
	IsLearner bool
}

// IsPaused returns whether sending log entries to this node has been throttled.
// This is done when a node has rejected recent MsgApps, is currently waiting
// for a snapshot, or has reached the MaxInflightMsgs limit. In normal
// operation, this is false. A throttled node will be contacted less frequently
// until it has reached a state in which it's able to accept a steady stream of
// log entries again.
func (pr *Progress) IsPaused() bool {
	switch pr.State {
	case StateProbe:
		return pr.ProbeSent
	case StateReplicate:
		return pr.Inflights.Full()
	case StateSnapshot:
		return true
	default:
		panic("unexpected state")
	}
}

// BecomeProbe transitions into StateProbe. Next is reset to Match+1 or,
// optionally and if larger, the index of the pending snapshot.
func (pr *Progress) BecomeProbe() {
	// If the original state is StateSnapshot, progress knows that
	// the pending snapshot has been sent to this peer successfully, then
	// probes from pendingSnapshot + 1.
	if pr.State == StateSnapshot {
		pendingSnapshot := pr.PendingSnapshot
		pr.ResetState(StateProbe)
		pr.Next = max(pr.Match+1, pendingSnapshot+1)
	} else {
		pr.ResetState(StateProbe)
		pr.Next = pr.Match + 1
	}
}

// BecomeReplicate transitions into StateReplicate, resetting Next to Match+1.
func (pr *Progress) BecomeReplicate() {
	pr.ResetState(StateReplicate)
	pr.Next = pr.Match + 1
}

// BecomeSnapshot moves the Progress to StateSnapshot with the specified pending
// snapshot index.
func (pr *Progress) BecomeSnapshot(snapshoti uint64) {
	pr.ResetState(StateSnapshot)
	pr.PendingSnapshot = snapshoti
}

// MaybeUpdate is called when an MsgAppResp arrives from the follower, with the
// index acked by it. The method returns false if the given n index comes from
// an outdated message. Otherwise it updates the progress and returns true.
func (pr *Progress) MaybeUpdate(n uint64) bool {
	var updated bool
	if pr.Match < n {
		pr.Match = n
		updated = true
		pr.ProbeAcked()
	}
	pr.Next = max(pr.Next, n+1)
	return updated
}

// OptimisticUpdate signals that appends all the way up to and including index n
// are in-flight. As a result, Next is increased to n+1.
func (pr *Progress) OptimisticUpdate(n uint64) { pr.Next = n + 1 }

// MaybeDecrTo adjusts the Progress to the receipt of a MsgApp rejection. The
// arguments are the index the follower rejected to append to its log, and its
// last index.
//
// Rejections can happen spuriously as messages are sent out of order or
// duplicated. In such cases, the rejection pertains to an index that the
// Progress already knows were previously acknowledged, and false is returned
// without changing the Progress.
//
// If the rejection is genuine, Next is lowered sensibly, and the Progress is
// cleared for sending log entries.
func (pr *Progress) MaybeDecrTo(rejected, last uint64) bool {
	if pr.State == StateReplicate {
		// The rejection must be stale if the progress has matched and "rejected"
		// is smaller than "match".
		if rejected <= pr.Match {
			return false
		}
		// Directly decrease next to match + 1.
		//
		// TODO(tbg): why not use last if it's larger?
		pr.Next = pr.Match + 1
		return true
	}

	// The rejection must be stale if "rejected" does not match next - 1. This
	// is because non-replicating followers are probed one entry at a time.
	if pr.Next-1 != rejected {
		return false
	}

	pr.Next = max(min(rejected, last+1), 1)
	pr.ProbeSent = false
	return true
}

func (r *raft) becomeLeader() {
	// ... ...
	r.reset(r.Term)
	// ... ...

	// Followers enter replicate mode when they've been successfully probed
	// (perhaps after having received a snapshot as a result). The leader is
	// trivially in this state. Note that r.reset() has initialized this
	// progress with the last index already.
	r.prs.Progress[r.id].BecomeReplicate()

	// ... ...

	emptyEnt := pb.Entry{Data: nil}
	if !r.appendEntry(emptyEnt) {
		// This won't happen because we just called reset() above.
		r.logger.Panic("empty entry was dropped")
	}
	// As a special case, don't count the initial empty entry towards the
	// uncommitted log quote. This is because we want to preserve the
	// behavior of allowing one entry larger than quote if the current
	// usage is zero.
	r.reduceUncommittedSize([]pb.Entry{emptyEnt})
	r.logger.Infof("%x became leader at term %d", r.id, r.Term)
}

func (r *raft) reset(term uint64) {
	// ... ...
	r.prs.ResetVotes()
	r.prs.Visit(func(id uint64, pr *tracker.Progress) {
		*pr = tracker.Progress{
			Match:     0,
			Next:      r.raftLog.lastIndex() + 1,
			Inflights: tracker.NewInflights(r.prs.MaxInflight),
			IsLearner: pr.IsLearner,
		}
		if id == r.id {
			pr.Match = r.raftLog.lastIndex()
		}
	})
	// ... ...
}

	// MaxUncommittedEntriesSize limits the aggregate byte size of the
	// uncommitted entries that may be appended to a leader's log. Once this
	// limit is exceeded, proposals will begin to return ErrProposalDropped
	// errors. Note: 0 for no limit.
	MaxUncommittedEntriesSize uint64

// increaseUncommittedSize computes the size of the proposed entries and
// determines whether they would push leader over its maxUncommittedSize limit.
// If the new entries would exceed the limit, the method returns false. If not,
// the increase in uncommitted entry size is recorded and the method returns
// true.
//
// Empty payloads are never refused. This is used both for appending an empty
// entry at a new leader's term, as well as leaving a joint configuration.
func (r *raft) increaseUncommittedSize(ents []pb.Entry) bool {
	var s uint64
	for _, e := range ents {
		s += uint64(PayloadSize(e))
	}

	if r.uncommittedSize > 0 && s > 0 && r.uncommittedSize+s > r.maxUncommittedSize {
		// If the uncommitted tail of the Raft log is empty, allow any size
		// proposal. Otherwise, limit the size of the uncommitted tail of the
		// log and drop any proposal that would push the size over the limit.
		// Note the added requirement s>0 which is used to make sure that
		// appending single empty entries to the log always succeeds, used both
		// for replicating a new leader's initial empty entry, and for
		// auto-leaving joint configurations.
		return false
	}
	r.uncommittedSize += s
	return true
}

// reduceUncommittedSize accounts for the newly committed entries by decreasing
// the uncommitted entry size limit.
func (r *raft) reduceUncommittedSize(ents []pb.Entry) {
	if r.uncommittedSize == 0 {
		// Fast-path for followers, who do not track or enforce the limit.
		return
	}

	var s uint64
	for _, e := range ents {
		s += uint64(PayloadSize(e))
	}
	if s > r.uncommittedSize {
		// uncommittedSize may underestimate the size of the uncommitted Raft
		// log tail but will never overestimate it. Saturate at 0 instead of
		// allowing overflow.
		r.uncommittedSize = 0
	} else {
		r.uncommittedSize -= s
	}
}

	// stepCandidate
	// ... ...
	case pb.MsgProp:
		r.logger.Infof("%x no leader at term %d; dropping proposal", r.id, r.Term)
		return ErrProposalDropped

	// stepFollower :
	// ... ...
	case pb.MsgProp:
		if r.lead == None {
			r.logger.Infof("%x no leader at term %d; dropping proposal", r.id, r.Term)
			return ErrProposalDropped
		} else if r.disableProposalForwarding {
			r.logger.Infof("%x not forwarding to leader %x at term %d; dropping proposal", r.id, r.lead, r.Term)
			return ErrProposalDropped
		}
		m.To = r.lead
		r.send(m)

	// stepLeader :
	// ... ...
	case pb.MsgProp:
		if len(m.Entries) == 0 {
			r.logger.Panicf("%x stepped empty MsgProp", r.id)
		}
		if r.prs.Progress[r.id] == nil {
			// If we are not currently a member of the range (i.e. this node
			// was removed from the configuration while serving as leader),
			// drop any new proposals.
			return ErrProposalDropped
		}
		if r.leadTransferee != None {
			r.logger.Debugf("%x [term %d] transfer leadership to %x is in progress; dropping proposal", r.id, r.Term, r.leadTransferee)
			return ErrProposalDropped
		}

		// Process ConfChange Msg
		//... ...

		if !r.appendEntry(m.Entries...) {
			return ErrProposalDropped
		}
		r.bcastAppend()
		return nil

// bcastAppend sends RPC, with entries to all peers that are not up-to-date
// according to the progress recorded in r.prs.
func (r *raft) bcastAppend() {
	r.prs.Visit(func(id uint64, _ *tracker.Progress) {
		if id == r.id {
			return
		}
		r.sendAppend(id)
	})
}

// sendAppend sends an append RPC with new entries (if any) and the
// current commit index to the given peer.
func (r *raft) sendAppend(to uint64) {
	r.maybeSendAppend(to, true)
}

// maybeSendAppend sends an append RPC with new entries to the given peer,
// if necessary. Returns true if a message was sent. The sendIfEmpty
// argument controls whether messages with no entries will be sent
// ("empty" messages are useful to convey updated Commit indexes, but
// are undesirable when we're sending multiple messages in a batch).
func (r *raft) maybeSendAppend(to uint64, sendIfEmpty bool) bool {
	pr := r.prs.Progress[to]
	if pr.IsPaused() {
		return false
	}
	m := pb.Message{}
	m.To = to

	term, errt := r.raftLog.term(pr.Next - 1)
	ents, erre := r.raftLog.entries(pr.Next, r.maxMsgSize)
	if len(ents) == 0 && !sendIfEmpty {
		return false
	}

	if errt != nil || erre != nil { // send snapshot if we failed to get term or entries

		// ... ... #1

	} else {

		// ... ... #2

	}
	r.send(m)
	return true
}

		// ... ... #2

		m.Type = pb.MsgApp
		m.Index = pr.Next - 1
		m.LogTerm = term
		m.Entries = ents
		m.Commit = r.raftLog.committed
		if n := len(m.Entries); n != 0 {
			switch pr.State {
			// optimistically increase the next when in StateReplicate
			case tracker.StateReplicate:
				last := m.Entries[n-1].Index
				pr.OptimisticUpdate(last)
				pr.Inflights.Add(last)
			case tracker.StateProbe:
				pr.ProbeSent = true
			default:
				r.logger.Panicf("%x is sending append in unhandled state %s", r.id, pr.State)
			}
		}

		// ... ... #1

		if !pr.RecentActive {
			r.logger.Debugf("ignore sending snapshot to %x since it is not recently active", to)
			return false
		}

		m.Type = pb.MsgSnap
		snapshot, err := r.raftLog.snapshot()
		if err != nil {
			if err == ErrSnapshotTemporarilyUnavailable {
				r.logger.Debugf("%x failed to send snapshot to %x because snapshot is temporarily unavailable", r.id, to)
				return false
			}
			panic(err) // TODO(bdarnell)
		}
		if IsEmptySnap(snapshot) {
			panic("need non-empty snapshot")
		}
		m.Snapshot = snapshot
		sindex, sterm := snapshot.Metadata.Index, snapshot.Metadata.Term
		r.logger.Debugf("%x [firstindex: %d, commit: %d] sent snapshot[index: %d, term: %d] to %x [%s]",
			r.id, r.raftLog.firstIndex(), r.raftLog.committed, sindex, sterm, to, pr)
		pr.BecomeSnapshot(sindex)
		r.logger.Debugf("%x paused sending replication messages to %x [%s]", r.id, to, pr)

// ReportSnapshot reports the status of the sent snapshot.
func (rn *RawNode) ReportSnapshot(id uint64, status SnapshotStatus) {
	rej := status == SnapshotFailure

	_ = rn.raft.Step(pb.Message{Type: pb.MsgSnapStatus, From: id, Reject: rej})
}

		// stepLeader
		// ... ...

		case pb.MsgSnapStatus:
		if pr.State != tracker.StateSnapshot {
			return nil
		}
		// TODO(tbg): this code is very similar to the snapshot handling in
		// MsgAppResp above. In fact, the code there is more correct than the
		// code here and should likely be updated to match (or even better, the
		// logic pulled into a newly created Progress state machine handler).
		if !m.Reject {
			pr.BecomeProbe()
			r.logger.Debugf("%x snapshot succeeded, resumed sending replication messages to %x [%s]", r.id, m.From, pr)
		} else {
			// NB: the order here matters or we'll be probing erroneously from
			// the snapshot index, but the snapshot never applied.
			pr.PendingSnapshot = 0
			pr.BecomeProbe()
			r.logger.Debugf("%x snapshot failed, resumed sending replication messages to %x [%s]", r.id, m.From, pr)
		}
		// If snapshot finish, wait for the MsgAppResp from the remote node before sending
		// out the next MsgApp.
		// If snapshot failure, wait for a heartbeat interval before next try
		pr.ProbeSent = true

func (r *raft) handleAppendEntries(m pb.Message) {
	if m.Index < r.raftLog.committed {
		r.send(pb.Message{To: m.From, Type: pb.MsgAppResp, Index: r.raftLog.committed})
		return
	}

	if mlastIndex, ok := r.raftLog.maybeAppend(m.Index, m.LogTerm, m.Commit, m.Entries...); ok {
		r.send(pb.Message{To: m.From, Type: pb.MsgAppResp, Index: mlastIndex})
	} else {
		r.logger.Debugf("%x [logterm: %d, index: %d] rejected MsgApp [logterm: %d, index: %d] from %x",
			r.id, r.raftLog.zeroTermOnErrCompacted(r.raftLog.term(m.Index)), m.Index, m.LogTerm, m.Index, m.From)
		r.send(pb.Message{To: m.From, Type: pb.MsgAppResp, Index: m.Index, Reject: true, RejectHint: r.raftLog.lastIndex()})
	}
}

func (r *raft) handleSnapshot(m pb.Message) {
	sindex, sterm := m.Snapshot.Metadata.Index, m.Snapshot.Metadata.Term
	if r.restore(m.Snapshot) {
		r.logger.Infof("%x [commit: %d] restored snapshot [index: %d, term: %d]",
			r.id, r.raftLog.committed, sindex, sterm)
		r.send(pb.Message{To: m.From, Type: pb.MsgAppResp, Index: r.raftLog.lastIndex()})
	} else {
		r.logger.Infof("%x [commit: %d] ignored snapshot [index: %d, term: %d]",
			r.id, r.raftLog.committed, sindex, sterm)
		r.send(pb.Message{To: m.From, Type: pb.MsgAppResp, Index: r.raftLog.committed})
	}
}

// restore recovers the state machine from a snapshot. It restores the log and the
// configuration of state machine. If this method returns false, the snapshot was
// ignored, either because it was obsolete or because of an error.
func (r *raft) restore(s pb.Snapshot) bool {
	if s.Metadata.Index <= r.raftLog.committed {
		return false
	}

	// ... ...

	// Now go ahead and actually restore.

	if r.raftLog.matchTerm(s.Metadata.Index, s.Metadata.Term) {
		r.logger.Infof("%x [commit: %d, lastindex: %d, lastterm: %d] fast-forwarded commit to snapshot [index: %d, term: %d]",
			r.id, r.raftLog.committed, r.raftLog.lastIndex(), r.raftLog.lastTerm(), s.Metadata.Index, s.Metadata.Term)
		r.raftLog.commitTo(s.Metadata.Index)
		return false
	}

	r.raftLog.restore(s)

	// ... ...

	r.logger.Infof("%x [commit: %d, lastindex: %d, lastterm: %d] restored snapshot [index: %d, term: %d]",
		r.id, r.raftLog.committed, r.raftLog.lastIndex(), r.raftLog.lastTerm(), s.Metadata.Index, s.Metadata.Term)
	return true
}


	// stepLeader
	// ... ...

	case pb.MsgAppResp:
		pr.RecentActive = true

		if m.Reject {
			r.logger.Debugf("%x received MsgAppResp(MsgApp was rejected, lastindex: %d) from %x for index %d",
				r.id, m.RejectHint, m.From, m.Index)
			if pr.MaybeDecrTo(m.Index, m.RejectHint) {
				r.logger.Debugf("%x decreased progress of %x to [%s]", r.id, m.From, pr)
				if pr.State == tracker.StateReplicate {
					pr.BecomeProbe()
				}
				r.sendAppend(m.From)
			}
		} else {
			oldPaused := pr.IsPaused()
			if pr.MaybeUpdate(m.Index) {
				switch {
				case pr.State == tracker.StateProbe:
					pr.BecomeReplicate()
				case pr.State == tracker.StateSnapshot && pr.Match >= pr.PendingSnapshot:
					// TODO(tbg): we should also enter this branch if a snapshot is
					// received that is below pr.PendingSnapshot but which makes it
					// possible to use the log again.
					r.logger.Debugf("%x recovered from needing snapshot, resumed sending replication messages to %x [%s]", r.id, m.From, pr)
					// Transition back to replicating state via probing state
					// (which takes the snapshot into account). If we didn't
					// move to replicating state, that would only happen with
					// the next round of appends (but there may not be a next
					// round for a while, exposing an inconsistent RaftStatus).
					pr.BecomeProbe()
					pr.BecomeReplicate()
				case pr.State == tracker.StateReplicate:
					pr.Inflights.FreeLE(m.Index)
				}

				if r.maybeCommit() {
					r.bcastAppend()
				} else if oldPaused {
					// If we were paused before, this node may be missing the
					// latest commit index, so send it.
					r.sendAppend(m.From)
				}
				// We've updated flow control information above, which may
				// allow us to send multiple (size-limited) in-flight messages
				// at once (such as when transitioning from probe to
				// replicate, or when freeTo() covers multiple messages). If
				// we have more entries to send, send as many messages as we
				// can (without sending empty messages for the commit index)
				for r.maybeSendAppend(m.From, false) {
				}

				// ... ...

			}
		}

// stepLeader
// ... ...
case pb.MsgBeat:
	r.bcastHeartbeat()

// ... ...

// sendHeartbeat sends a heartbeat RPC to the given peer.
func (r *raft) sendHeartbeat(to uint64, ctx []byte) {
	// Attach the commit as min(to.matched, r.committed).
	// When the leader sends out heartbeat message,
	// the receiver(follower) might not be matched with the leader
	// or it might not have all the committed entries.
	// The leader MUST NOT forward the follower's commit to
	// an unmatched index.
	commit := min(r.prs.Progress[to].Match, r.raftLog.committed)
	m := pb.Message{
		To:      to,
		Type:    pb.MsgHeartbeat,
		Commit:  commit,
		Context: ctx,
	}

	r.send(m)
}

func (r *raft) handleHeartbeat(m pb.Message) {
	r.raftLog.commitTo(m.Commit)
	r.send(pb.Message{To: m.From, Type: pb.MsgHeartbeatResp, Context: m.Context})
}

	case pb.MsgHeartbeatResp:
		pr.RecentActive = true
		pr.ProbeSent = false

		// free one slot for the full inflights window to allow progress.
		if pr.State == tracker.StateReplicate && pr.Inflights.Full() {
			pr.Inflights.FreeFirstOne()
		}
		if pr.Match < r.raftLog.lastIndex() {
			r.sendAppend(m.From)
		}

		// ... ...

// node.go
func newReady(r *raft, prevSoftSt *SoftState, prevHardSt pb.HardState) Ready {
	rd := Ready{
		Entries:          r.raftLog.unstableEntries(),
		CommittedEntries: r.raftLog.nextEnts(),
		Messages:         r.msgs,
	}
	if softSt := r.softState(); !softSt.equal(prevSoftSt) {
		rd.SoftState = softSt
	}
	if hardSt := r.hardState(); !isHardStateEqual(hardSt, prevHardSt) {
		rd.HardState = hardSt
	}
	if r.raftLog.unstable.snapshot != nil {
		rd.Snapshot = *r.raftLog.unstable.snapshot
	}
	if len(r.readStates) != 0 {
		rd.ReadStates = r.readStates
	}
	rd.MustSync = MustSync(r.hardState(), prevHardSt, len(rd.Entries))
	return rd
}

// log.go
func (l *raftLog) unstableEntries() []pb.Entry {
	if len(l.unstable.entries) == 0 {
		return nil
	}
	return l.unstable.entries
}

// raft.go
func (r *raft) loadState(state pb.HardState) {
	if state.Commit < r.raftLog.committed || state.Commit > r.raftLog.lastIndex() {
		r.logger.Panicf("%x state.commit %d is out of range [%d, %d]", r.id, state.Commit, r.raftLog.committed, r.raftLog.lastIndex())
	}
	r.raftLog.committed = state.Commit
	r.Term = state.Term
	r.Vote = state.Vote
}
