深入浅出etcd/raft —— 0x03 Raft选举

// *** node.go ***

func (n *node) Campaign(ctx context.Context) error { return n.step(ctx, pb.Message{Type: pb.MsgHup}) }

// *** rawnode.go ***

func (rn *RawNode) Campaign() error {
	return rn.raft.Step(pb.Message{
		Type: pb.MsgHup,
	})
}

// *** raft.go ***

// tickElection is run by followers and candidates after r.electionTimeout.
func (r *raft) tickElection() {
	r.electionElapsed++

	if r.promotable() && r.pastElectionTimeout() {
		r.electionElapsed = 0
		r.Step(pb.Message{From: r.id, Type: pb.MsgHup})
	}
}

func (r *raft) Step(m pb.Message) error {
	// ... ...
	switch m.Type {
	case pb.MsgHup:
		if r.preVote {
			r.hup(campaignPreElection)
		} else {
			r.hup(campaignElection)
		}
	// ... ...
	}
	// ... ...
}

func (r *raft) hup(t CampaignType) {
	if r.state == StateLeader {
		r.logger.Debugf("%x ignoring MsgHup because already leader", r.id)
		return
	}

	if !r.promotable() {
		r.logger.Warningf("%x is unpromotable and can not campaign", r.id)
		return
	}
	ents, err := r.raftLog.slice(r.raftLog.applied+1, r.raftLog.committed+1, noLimit)
	if err != nil {
		r.logger.Panicf("unexpected error getting unapplied entries (%v)", err)
	}
	if n := numOfPendingConf(ents); n != 0 && r.raftLog.committed > r.raftLog.applied {
		r.logger.Warningf("%x cannot campaign at term %d since there are still %d pending configuration changes to apply", r.id, r.Term, n)
		return
	}

	r.logger.Infof("%x is starting a new election at term %d", r.id, r.Term)
	r.campaign(t)
}

// promotable indicates whether state machine can be promoted to leader,
// which is true when its own id is in progress list.
func (r *raft) promotable() bool {
	pr := r.prs.Progress[r.id]
	return pr != nil && !pr.IsLearner && !r.raftLog.hasPendingSnapshot()
}

// campaign transitions the raft instance to candidate state. This must only be
// called after verifying that this is a legitimate transition.
func (r *raft) campaign(t CampaignType) {
	if !r.promotable() {
		// This path should not be hit (callers are supposed to check), but
		// better safe than sorry.
		r.logger.Warningf("%x is unpromotable; campaign() should have been called", r.id)
	}
	var term uint64
	var voteMsg pb.MessageType
	if t == campaignPreElection {
		r.becomePreCandidate()
		voteMsg = pb.MsgPreVote
		// PreVote RPCs are sent for the next term before we've incremented r.Term.
		term = r.Term + 1
	} else {
		r.becomeCandidate()
		voteMsg = pb.MsgVote
		term = r.Term
	}
	if _, _, res := r.poll(r.id, voteRespMsgType(voteMsg), true); res == quorum.VoteWon {
		// We won the election after voting for ourselves (which must mean that
		// this is a single-node cluster). Advance to the next state.
		if t == campaignPreElection {
			r.campaign(campaignElection)
		} else {
			r.becomeLeader()
		}
		return
	}
	var ids []uint64
	{
		idMap := r.prs.Voters.IDs()
		ids = make([]uint64, 0, len(idMap))
		for id := range idMap {
			ids = append(ids, id)
		}
		sort.Slice(ids, func(i, j int) bool { return ids[i] < ids[j] })
	}
	for _, id := range ids {
		if id == r.id {
			continue
		}
		r.logger.Infof("%x [logterm: %d, index: %d] sent %s request to %x at term %d",
			r.id, r.raftLog.lastTerm(), r.raftLog.lastIndex(), voteMsg, id, r.Term)

		var ctx []byte
		if t == campaignTransfer {
			ctx = []byte(t)
		}
		r.send(pb.Message{Term: term, To: id, Type: voteMsg, Index: r.raftLog.lastIndex(), LogTerm: r.raftLog.lastTerm(), Context: ctx})
	}
}

	if t == campaignPreElection {
		r.becomePreCandidate()
		voteMsg = pb.MsgPreVote
		// PreVote RPCs are sent for the next term before we've incremented r.Term.
		term = r.Term + 1
	} else {
		r.becomeCandidate()
		voteMsg = pb.MsgVote
		term = r.Term
	}

		if _, _, res := r.poll(r.id, voteRespMsgType(voteMsg), true); res == quorum.VoteWon {
		// We won the election after voting for ourselves (which must mean that
		// this is a single-node cluster). Advance to the next state.
		if t == campaignPreElection {
			r.campaign(campaignElection)
		} else {
			r.becomeLeader()
		}
		return
	}

	var ids []uint64
	{
		idMap := r.prs.Voters.IDs()
		ids = make([]uint64, 0, len(idMap))
		for id := range idMap {
			ids = append(ids, id)
		}
		sort.Slice(ids, func(i, j int) bool { return ids[i] < ids[j] })
	}
	for _, id := range ids {
		if id == r.id {
			continue
		}
		r.logger.Infof("%x [logterm: %d, index: %d] sent %s request to %x at term %d",
			r.id, r.raftLog.lastTerm(), r.raftLog.lastIndex(), voteMsg, id, r.Term)

		var ctx []byte
		if t == campaignTransfer {
			ctx = []byte(t)
		}
		r.send(pb.Message{Term: term, To: id, Type: voteMsg, Index: r.raftLog.lastIndex(), LogTerm: r.raftLog.lastTerm(), Context: ctx})
	}

// Definition of `stepFunc`
type stepFunc func(r *raft, m pb.Message) error

// step field in struct `raft`
step stepFunc

	// Handle the message term, which may result in our stepping down to a follower.
	switch {
	case m.Term == 0:
		// local message

	// case ... ...

	}

	case m.Term > r.Term:
		if m.Type == pb.MsgVote || m.Type == pb.MsgPreVote {
			force := bytes.Equal(m.Context, []byte(campaignTransfer))
			inLease := r.checkQuorum && r.lead != None && r.electionElapsed < r.electionTimeout
			if !force && inLease {
				// If a server receives a RequestVote request within the minimum election timeout
				// of hearing from a current leader, it does not update its term or grant its vote
				r.logger.Infof("%x [logterm: %d, index: %d, vote: %x] ignored %s from %x [logterm: %d, index: %d] at term %d: lease is not expired (remaining ticks: %d)",
					r.id, r.raftLog.lastTerm(), r.raftLog.lastIndex(), r.Vote, m.Type, m.From, m.LogTerm, m.Index, r.Term, r.electionTimeout-r.electionElapsed)
				return nil
			}
		}
		switch {
		case m.Type == pb.MsgPreVote:
			// Never change our term in response to a PreVote
		case m.Type == pb.MsgPreVoteResp && !m.Reject:
			// We send pre-vote requests with a term in our future. If the
			// pre-vote is granted, we will increment our term when we get a
			// quorum. If it is not, the term comes from the node that
			// rejected our vote so we should become a follower at the new
			// term.
		default:
			r.logger.Infof("%x [term: %d] received a %s message with higher term from %x [term: %d]",
				r.id, r.Term, m.Type, m.From, m.Term)
			if m.Type == pb.MsgApp || m.Type == pb.MsgHeartbeat || m.Type == pb.MsgSnap {
				r.becomeFollower(m.Term, m.From)
			} else {
				r.becomeFollower(m.Term, None)
			}
		}

case m.Term < r.Term:
		if (r.checkQuorum || r.preVote) && (m.Type == pb.MsgHeartbeat || m.Type == pb.MsgApp) {
			// We have received messages from a leader at a lower term. It is possible
			// that these messages were simply delayed in the network, but this could
			// also mean that this node has advanced its term number during a network
			// partition, and it is now unable to either win an election or to rejoin
			// the majority on the old term. If checkQuorum is false, this will be
			// handled by incrementing term numbers in response to MsgVote with a
			// higher term, but if checkQuorum is true we may not advance the term on
			// MsgVote and must generate other messages to advance the term. The net
			// result of these two features is to minimize the disruption caused by
			// nodes that have been removed from the cluster's configuration: a
			// removed node will send MsgVotes (or MsgPreVotes) which will be ignored,
			// but it will not receive MsgApp or MsgHeartbeat, so it will not create
			// disruptive term increases, by notifying leader of this node's activeness.
			// The above comments also true for Pre-Vote
			//
			// When follower gets isolated, it soon starts an election ending
			// up with a higher term than leader, although it won't receive enough
			// votes to win the election. When it regains connectivity, this response
			// with "pb.MsgAppResp" of higher term would force leader to step down.
			// However, this disruption is inevitable to free this stuck node with
			// fresh election. This can be prevented with Pre-Vote phase.
			r.send(pb.Message{To: m.From, Type: pb.MsgAppResp})
		} else if m.Type == pb.MsgPreVote {
			// Before Pre-Vote enable, there may have candidate with higher term,
			// but less log. After update to Pre-Vote, the cluster may deadlock if
			// we drop messages with a lower term.
			r.logger.Infof("%x [logterm: %d, index: %d, vote: %x] rejected %s from %x [logterm: %d, index: %d] at term %d",
				r.id, r.raftLog.lastTerm(), r.raftLog.lastIndex(), r.Vote, m.Type, m.From, m.LogTerm, m.Index, r.Term)
			r.send(pb.Message{To: m.From, Term: r.Term, Type: pb.MsgPreVoteResp, Reject: true})
		} else {
			// ignore other cases
			r.logger.Infof("%x [term: %d] ignored a %s message with lower term from %x [term: %d]",
				r.id, r.Term, m.Type, m.From, m.Term)
		}
		return nil
	}

	switch m.Type {
	case pb.MsgHup:
		if r.preVote {
			r.hup(campaignPreElection)
		} else {
			r.hup(campaignElection)
		}

	case pb.MsgVote, pb.MsgPreVote:
		// We can vote if this is a repeat of a vote we've already cast...
		canVote := r.Vote == m.From ||
			// ...we haven't voted and we don't think there's a leader yet in this term...
			(r.Vote == None && r.lead == None) ||
			// ...or this is a PreVote for a future term...
			(m.Type == pb.MsgPreVote && m.Term > r.Term)
		// ...and we believe the candidate is up to date.
		if canVote && r.raftLog.isUpToDate(m.Index, m.LogTerm) {
			// Note: it turns out that that learners must be allowed to cast votes.
			// This seems counter- intuitive but is necessary in the situation in which
			// a learner has been promoted (i.e. is now a voter) but has not learned
			// about this yet.
			// For example, consider a group in which id=1 is a learner and id=2 and
			// id=3 are voters. A configuration change promoting 1 can be committed on
			// the quorum `{2,3}` without the config change being appended to the
			// learner's log. If the leader (say 2) fails, there are de facto two
			// voters remaining. Only 3 can win an election (due to its log containing
			// all committed entries), but to do so it will need 1 to vote. But 1
			// considers itself a learner and will continue to do so until 3 has
			// stepped up as leader, replicates the conf change to 1, and 1 applies it.
			// Ultimately, by receiving a request to vote, the learner realizes that
			// the candidate believes it to be a voter, and that it should act
			// accordingly. The candidate's config may be stale, too; but in that case
			// it won't win the election, at least in the absence of the bug discussed
			// in:
			// https://github.com/etcd-io/etcd/issues/7625#issuecomment-488798263.
			r.logger.Infof("%x [logterm: %d, index: %d, vote: %x] cast %s for %x [logterm: %d, index: %d] at term %d",
				r.id, r.raftLog.lastTerm(), r.raftLog.lastIndex(), r.Vote, m.Type, m.From, m.LogTerm, m.Index, r.Term)
			// When responding to Msg{Pre,}Vote messages we include the term
			// from the message, not the local term. To see why, consider the
			// case where a single node was previously partitioned away and
			// it's local term is now out of date. If we include the local term
			// (recall that for pre-votes we don't update the local term), the
			// (pre-)campaigning node on the other end will proceed to ignore
			// the message (it ignores all out of date messages).
			// The term in the original message and current local term are the
			// same in the case of regular votes, but different for pre-votes.
			r.send(pb.Message{To: m.From, Term: m.Term, Type: voteRespMsgType(m.Type)})
			if m.Type == pb.MsgVote {
				// Only record real votes.
				r.electionElapsed = 0
				r.Vote = m.From
			}
		} else {
			r.logger.Infof("%x [logterm: %d, index: %d, vote: %x] rejected %s from %x [logterm: %d, index: %d] at term %d",
				r.id, r.raftLog.lastTerm(), r.raftLog.lastIndex(), r.Vote, m.Type, m.From, m.LogTerm, m.Index, r.Term)
			r.send(pb.Message{To: m.From, Term: r.Term, Type: voteRespMsgType(m.Type), Reject: true})
		}

	default:
		err := r.step(r, m)
		if err != nil {
			return err
		}
	}
	return nil
}

func (r *raft) becomeCandidate() {
	// ... ...
	r.step = stepCandidate
	r.reset(r.Term + 1)
	r.tick = r.tickElection
	r.Vote = r.id
	r.state = StateCandidate
	r.logger.Infof("%x became candidate at term %d", r.id, r.Term)
}

func (r *raft) becomePreCandidate() {
	// ... ...
	// Becoming a pre-candidate changes our step functions and state,
	// but doesn't change anything else. In particular it does not increase
	// r.Term or change r.Vote.
	r.step = stepCandidate
	r.prs.ResetVotes()
	r.tick = r.tickElection
	r.lead = None
	r.state = StatePreCandidate
	r.logger.Infof("%x became pre-candidate at term %d", r.id, r.Term)
}

func (r *raft) reset(term uint64) {
	if r.Term != term {
		r.Term = term
		r.Vote = None
	}
	r.lead = None

	r.electionElapsed = 0
	r.heartbeatElapsed = 0
	r.resetRandomizedElectionTimeout()

	r.abortLeaderTransfer()

	r.prs.ResetVotes()

	// ... ...

}

// stepCandidate is shared by StateCandidate and StatePreCandidate; the difference is
// whether they respond to MsgVoteResp or MsgPreVoteResp.
func stepCandidate(r *raft, m pb.Message) error {
	// Only handle vote responses corresponding to our candidacy (while in
	// StateCandidate, we may get stale MsgPreVoteResp messages in this term from
	// our pre-candidate state).
	var myVoteRespType pb.MessageType
	if r.state == StatePreCandidate {
		myVoteRespType = pb.MsgPreVoteResp
	} else {
		myVoteRespType = pb.MsgVoteResp
	}
	switch m.Type {
	case pb.MsgProp:
		r.logger.Infof("%x no leader at term %d; dropping proposal", r.id, r.Term)
		return ErrProposalDropped
	case pb.MsgApp:
		r.becomeFollower(m.Term, m.From) // always m.Term == r.Term
		r.handleAppendEntries(m)
	case pb.MsgHeartbeat:
		r.becomeFollower(m.Term, m.From) // always m.Term == r.Term
		r.handleHeartbeat(m)
	case pb.MsgSnap:
		r.becomeFollower(m.Term, m.From) // always m.Term == r.Term
		r.handleSnapshot(m)
	case myVoteRespType:
		gr, rj, res := r.poll(m.From, m.Type, !m.Reject)
		r.logger.Infof("%x has received %d %s votes and %d vote rejections", r.id, gr, m.Type, rj)
		switch res {
		case quorum.VoteWon:
			if r.state == StatePreCandidate {
				r.campaign(campaignElection)
			} else {
				r.becomeLeader()
				r.bcastAppend()
			}
		case quorum.VoteLost:
			// pb.MsgPreVoteResp contains future term of pre-candidate
			// m.Term > r.Term; reuse r.Term
			r.becomeFollower(r.Term, None)
		}
	case pb.MsgTimeoutNow:
		r.logger.Debugf("%x [term %d state %v] ignored MsgTimeoutNow from %x", r.id, r.Term, r.state, m.From)
	}
	return nil
}

func (r *raft) becomeLeader() {
	// ... ...
	r.step = stepLeader
	r.reset(r.Term)
	r.tick = r.tickHeartbeat
	r.lead = r.id
	r.state = StateLeader
	// ... ...
}

func stepLeader(r *raft, m pb.Message) error {
	// These message types do not require any progress for m.From.
	switch m.Type {
	case pb.MsgBeat:
		r.bcastHeartbeat()
		return nil
	case pb.MsgCheckQuorum:
		// The leader should always see itself as active. As a precaution, handle
		// the case in which the leader isn't in the configuration any more (for
		// example if it just removed itself).
		//
		// TODO(tbg): I added a TODO in removeNode, it doesn't seem that the
		// leader steps down when removing itself. I might be missing something.
		if pr := r.prs.Progress[r.id]; pr != nil {
			pr.RecentActive = true
		}
		if !r.prs.QuorumActive() {
			r.logger.Warningf("%x stepped down to follower since quorum is not active", r.id)
			r.becomeFollower(r.Term, None)
		}
		// Mark everyone (but ourselves) as inactive in preparation for the next
		// CheckQuorum.
		r.prs.Visit(func(id uint64, pr *tracker.Progress) {
			if id != r.id {
				pr.RecentActive = false
			}
		})
		return nil
	// ... ...
	}

	// All other message types require a progress for m.From (pr).
	pr := r.prs.Progress[m.From]
	if pr == nil {
		r.logger.Debugf("%x no progress available for %x", r.id, m.From)
		return nil
	}
	switch m.Type {
	// ... ...
	case pb.MsgTransferLeader:
		if pr.IsLearner {
			r.logger.Debugf("%x is learner. Ignored transferring leadership", r.id)
			return nil
		}
		leadTransferee := m.From
		lastLeadTransferee := r.leadTransferee
		if lastLeadTransferee != None {
			if lastLeadTransferee == leadTransferee {
				r.logger.Infof("%x [term %d] transfer leadership to %x is in progress, ignores request to same node %x",
					r.id, r.Term, leadTransferee, leadTransferee)
				return nil
			}
			r.abortLeaderTransfer()
			r.logger.Infof("%x [term %d] abort previous transferring leadership to %x", r.id, r.Term, lastLeadTransferee)
		}
		if leadTransferee == r.id {
			r.logger.Debugf("%x is already leader. Ignored transferring leadership to self", r.id)
			return nil
		}
		// Transfer leadership to third party.
		r.logger.Infof("%x [term %d] starts to transfer leadership to %x", r.id, r.Term, leadTransferee)
		// Transfer leadership should be finished in one electionTimeout, so reset r.electionElapsed.
		r.electionElapsed = 0
		r.leadTransferee = leadTransferee
		if pr.Match == r.raftLog.lastIndex() {
			r.sendTimeoutNow(leadTransferee)
			r.logger.Infof("%x sends MsgTimeoutNow to %x immediately as %x already has up-to-date log", r.id, leadTransferee, leadTransferee)
		} else {
			r.sendAppend(leadTransferee)
		}
	}
	return nil
}

// Transfer leadership is in progress.
if m.From == r.leadTransferee && pr.Match == r.raftLog.lastIndex() {
	r.logger.Infof("%x sent MsgTimeoutNow to %x after received MsgAppResp", r.id, m.From)
	r.sendTimeoutNow(m.From)
}

func (r *raft) becomeFollower(term uint64, lead uint64) {
	r.step = stepFollower
	r.reset(term)
	r.tick = r.tickElection
	r.lead = lead
	r.state = StateFollower
	r.logger.Infof("%x became follower at term %d", r.id, r.Term)
}

func stepFollower(r *raft, m pb.Message) error {
	switch m.Type {
	// ... ...
	case pb.MsgApp:
		r.electionElapsed = 0
		r.lead = m.From
		// ... ...
	case pb.MsgHeartbeat:
		r.electionElapsed = 0
		r.lead = m.From
		// ... ...
	case pb.MsgSnap:
		r.electionElapsed = 0
		r.lead = m.From
		// ... ...
	case pb.MsgTransferLeader:
		if r.lead == None {
			r.logger.Infof("%x no leader at term %d; dropping leader transfer msg", r.id, r.Term)
			return nil
		}
		m.To = r.lead
		r.send(m)
	case pb.MsgTimeoutNow:
		r.logger.Infof("%x [term %d] received MsgTimeoutNow from %x and starts an election to get leadership.", r.id, r.Term, m.From)
		// Leadership transfers never use pre-vote even if r.preVote is true; we
		// know we are not recovering from a partition so there is no need for the
		// extra round trip.
		r.hup(campaignTransfer)
	// ... ...
	return nil
}
