深入浅出boltdb —— 0x01 存储与缓存

type pgid uint64

type page struct {
	id       pgid
	flags    uint16
	count    uint16
	overflow uint32
	ptr      uintptr
}

type meta struct {
	magic    uint32
	version  uint32
	pageSize uint32
	flags    uint32
	root     bucket
	freelist pgid
	pgid     pgid
	txid     txid
	checksum uint64
}

// bucket.go

type bucket struct {
	root     pgid   // page id of the bucket's root-level page
	sequence uint64 // monotonically incrementing, used by NextSequence()
}

// branchPageElement represents a node on a branch page.
type branchPageElement struct {
	pos   uint32
	ksize uint32
	pgid  pgid
}

// key returns a byte slice of the node key.
func (n *branchPageElement) key() []byte {
	buf := (*[maxAllocSize]byte)(unsafe.Pointer(n))
	return (*[maxAllocSize]byte)(unsafe.Pointer(&buf[n.pos]))[:n.ksize]
}

// leafPageElement represents a node on a leaf page.
type leafPageElement struct {
	flags uint32
	pos   uint32
	ksize uint32
	vsize uint32
}

// key returns a byte slice of the node key.
func (n *leafPageElement) key() []byte {
	buf := (*[maxAllocSize]byte)(unsafe.Pointer(n))
	return (*[maxAllocSize]byte)(unsafe.Pointer(&buf[n.pos]))[:n.ksize:n.ksize]
}

// value returns a byte slice of the node value.
func (n *leafPageElement) value() []byte {
	buf := (*[maxAllocSize]byte)(unsafe.Pointer(n))
	return (*[maxAllocSize]byte)(unsafe.Pointer(&buf[n.pos+n.ksize]))[:n.vsize:n.vsize]
}

// freelist represents a list of all pages that are available for allocation.
// It also tracks pages that have been freed but are still in use by open transactions.
type freelist struct {
	ids     []pgid          // all free and available free page ids.
	pending map[txid][]pgid // mapping of soon-to-be free page ids by tx.
	cache   map[pgid]bool   // fast lookup of all free and pending page ids.
}

// read initializes the freelist from a freelist page.
func (f *freelist) read(p *page) {
	// If the page.count is at the max uint16 value (64k) then it's considered
	// an overflow and the size of the freelist is stored as the first element.
	idx, count := 0, int(p.count)
	if count == 0xFFFF {
		idx = 1
		count = int(((*[maxAllocSize]pgid)(unsafe.Pointer(&p.ptr)))[0])
	}

	// Copy the list of page ids from the freelist.
	if count == 0 {
		f.ids = nil
	} else {
		ids := ((*[maxAllocSize]pgid)(unsafe.Pointer(&p.ptr)))[idx:count]
		f.ids = make([]pgid, len(ids))
		copy(f.ids, ids)

		// Make sure they're sorted.
		sort.Sort(pgids(f.ids))
	}

	// Rebuild the page cache.
	f.reindex()
}

// write writes the page ids onto a freelist page. All free and pending ids are
// saved to disk since in the event of a program crash, all pending ids will
// become free.
func (f *freelist) write(p *page) error {
	// Combine the old free pgids and pgids waiting on an open transaction.

	// Update the header flag.
	p.flags |= freelistPageFlag

	// The page.count can only hold up to 64k elements so if we overflow that
	// number then we handle it by putting the size in the first element.
	lenids := f.count()
	if lenids == 0 {
		p.count = uint16(lenids)
	} else if lenids < 0xFFFF {
		p.count = uint16(lenids)
		f.copyall(((*[maxAllocSize]pgid)(unsafe.Pointer(&p.ptr)))[:])
	} else {
		p.count = 0xFFFF
		((*[maxAllocSize]pgid)(unsafe.Pointer(&p.ptr)))[0] = pgid(lenids)
		f.copyall(((*[maxAllocSize]pgid)(unsafe.Pointer(&p.ptr)))[1:])
	}

	return nil
}

func (db *DB) beginRWTx() (*Tx, error) {

	// ... ...

	// Free any pages associated with closed read-only transactions.
	var minid txid = 0xFFFFFFFFFFFFFFFF
	for _, t := range db.txs {
		if t.meta.txid < minid {
			minid = t.meta.txid
		}
	}
	if minid > 0 {
		db.freelist.release(minid - 1)
	}

	return t, nil
}

// mmap opens the underlying memory-mapped file and initializes the meta references.
// minsz is the minimum size that the new mmap can be.
func (db *DB) mmap(minsz int) error {
	db.mmaplock.Lock()
	defer db.mmaplock.Unlock()

	info, err := db.file.Stat()
	if err != nil {
		return fmt.Errorf("mmap stat error: %s", err)
	} else if int(info.Size()) < db.pageSize*2 {
		return fmt.Errorf("file size too small")
	}

	// Ensure the size is at least the minimum size.
	var size = int(info.Size())
	if size < minsz {
		size = minsz
	}
	size, err = db.mmapSize(size)
	if err != nil {
		return err
	}

	// Dereference all mmap references before unmapping.
	if db.rwtx != nil {
		db.rwtx.root.dereference()
	}

	// Unmap existing data before continuing.
	if err := db.munmap(); err != nil {
		return err
	}

	// Memory-map the data file as a byte slice.
	if err := mmap(db, size); err != nil {
		return err
	}

	// Save references to the meta pages.
	db.meta0 = db.page(0).meta()
	db.meta1 = db.page(1).meta()

	// Validate the meta pages. We only return an error if both meta pages fail
	// validation, since meta0 failing validation means that it wasn't saved
	// properly -- but we can recover using meta1. And vice-versa.
	err0 := db.meta0.validate()
	err1 := db.meta1.validate()
	if err0 != nil && err1 != nil {
		return err0
	}

	return nil
}

// munmap unmaps the data file from memory.
func (db *DB) munmap() error {
	if err := munmap(db); err != nil {
		return fmt.Errorf("unmap error: " + err.Error())
	}
	return nil
}

// mmapSize determines the appropriate size for the mmap given the current size
// of the database. The minimum size is 32KB and doubles until it reaches 1GB.
// Returns an error if the new mmap size is greater than the max allowed.
func (db *DB) mmapSize(size int) (int, error) {
	// Double the size from 32KB until 1GB.
	for i := uint(15); i <= 30; i++ {
		if size <= 1<<i {
			return 1 << i, nil
		}
	}

	// Verify the requested size is not above the maximum allowed.
	if size > maxMapSize {
		return 0, fmt.Errorf("mmap too large")
	}

	// If larger than 1GB then grow by 1GB at a time.
	sz := int64(size)
	if remainder := sz % int64(maxMmapStep); remainder > 0 {
		sz += int64(maxMmapStep) - remainder
	}

	// Ensure that the mmap size is a multiple of the page size.
	// This should always be true since we're incrementing in MBs.
	pageSize := int64(db.pageSize)
	if (sz % pageSize) != 0 {
		sz = ((sz / pageSize) + 1) * pageSize
	}

	// If we've exceeded the max size then only grow up to the max size.
	if sz > maxMapSize {
		sz = maxMapSize
	}

	return int(sz), nil
}

// allocate returns a contiguous block of memory starting at a given page.
func (db *DB) allocate(count int) (*page, error) {
	// Allocate a temporary buffer for the page.
	var buf []byte
	if count == 1 {
		buf = db.pagePool.Get().([]byte)
	} else {
		buf = make([]byte, count*db.pageSize)
	}
	p := (*page)(unsafe.Pointer(&buf[0]))
	p.overflow = uint32(count - 1)

	// Use pages from the freelist if they are available.
	if p.id = db.freelist.allocate(count); p.id != 0 {
		return p, nil
	}

	// Resize mmap() if we're at the end.
	p.id = db.rwtx.meta.pgid
	var minsz = int((p.id+pgid(count))+1) * db.pageSize
	if minsz >= db.datasz {
		if err := db.mmap(minsz); err != nil {
			return nil, fmt.Errorf("mmap allocate error: %s", err)
		}
	}

	// Move the page id high water mark.
	db.rwtx.meta.pgid += pgid(count)

	return p, nil
}

	// in struct db
	pagePool sync.Pool

	// in `db.Open`
	// Initialize page pool.
	db.pagePool = sync.Pool{
		New: func() interface{} {
			return make([]byte, db.pageSize)
		},
	}

// write writes any dirty pages to disk.
func (tx *Tx) write() error {
	// Sort pages by id.
	pages := make(pages, 0, len(tx.pages))
	for _, p := range tx.pages {
		pages = append(pages, p)
	}
	// Clear out page cache early.
	tx.pages = make(map[pgid]*page)
	sort.Sort(pages)

	// Write pages to disk in order.
	for _, p := range pages {
		size := (int(p.overflow) + 1) * tx.db.pageSize
		offset := int64(p.id) * int64(tx.db.pageSize)

		// Write out page in "max allocation" sized chunks.
		ptr := (*[maxAllocSize]byte)(unsafe.Pointer(p))
		for {
			// Limit our write to our max allocation size.
			sz := size
			if sz > maxAllocSize-1 {
				sz = maxAllocSize - 1
			}

			// Write chunk to disk.
			buf := ptr[:sz]
			if _, err := tx.db.ops.writeAt(buf, offset); err != nil {
				return err
			}

			// Update statistics.
			tx.stats.Write++

			// Exit inner for loop if we've written all the chunks.
			size -= sz
			if size == 0 {
				break
			}

			// Otherwise move offset forward and move pointer to next chunk.
			offset += int64(sz)
			ptr = (*[maxAllocSize]byte)(unsafe.Pointer(&ptr[sz]))
		}
	}

	// Ignore file sync if flag is set on DB.
	if !tx.db.NoSync || IgnoreNoSync {
		if err := fdatasync(tx.db); err != nil {
			return err
		}
	}

	// Put small pages back to page pool.
	for _, p := range pages {
		// Ignore page sizes over 1 page.
		// These are allocated using make() instead of the page pool.
		if int(p.overflow) != 0 {
			continue
		}

		buf := (*[maxAllocSize]byte)(unsafe.Pointer(p))[:tx.db.pageSize]

		// See https://go.googlesource.com/go/+/f03c9202c43e0abb130669852082117ca50aa9b1
		for i := range buf {
			buf[i] = 0
		}
		tx.db.pagePool.Put(buf)
	}

	return nil
}
